Feature:
* Metal panel, high performance electronic circuit design
* Built-in Hi-Fi professional audio range restriction chip, high factor audio channel crosstalk.
* SMT production, classic Hi-Fi digital PWM chip
* High effective radiator, double speed, low noise radiator fan, standard 2U height design
* 2 audio channel output, 4 channel output 120W, 2 channel output 350W.
* Low noise electric level and zero point voltage, 20Hz~2KHz frequency response is only +/-1dB
* Safety protection: short circuit, overload, high temperature, vibration amplitude, direct current protection.
Specification:
Model No.: AV-2018
Color: Black
Type: Post-Amplifier
Channel: 4
Output power (stereo 8Ω): 1KHZ, 1.0% THD+N 120Wx4
Output power (stereo 4Ω): 1KHZ, 1.0% THD+N 182Wx4
Output power (bridge 8Ω): 1KHZ, 1.0% THD+N 350Wx4
Noise level: <3.0mV Frequency response: 20Hz~20KHz Input impedance: 20KΩ Input sensitivity: stereo @8Ω RMS 1KHZ, 1.0% THD+N, 1V Load impedance: 8~4Ω S/N: stereo @8Ω RMS 1KHZ, 1.0% THD+N, >80dB
Voltage gain: stereo @8Ω RMS 1KHZ, 1.0% THD+N, 72dB
Damping factor: stereo @8Ω RMS 400HZ, 1.0% THD+N, 200
THD: ≤0.5%
Circuit protection: 20Hz~20KHz output 3V
Power: AC220V
Cabinet dimension(L*W*H): 485*337*100mm
Package dimension(L*W*H): 550*410*175mm
Net weight: 9.8kg
